What is the function of Tee Joint Box?

The self-limiting electric heating cable can automatically limit the heating temperature, and automatically adjust the output power according to the temperature of the heating body. During the installation process, it can be cut arbitrarily or extended within a certain length range, so "straight running" is usually used. And "T-shaped" junction box, that is, the so-called Tee Joint Box, its main function is to connect the straight-through or intersection of the heating cable.

What are the product features of Tee Joint Box?

What are the steps to use the Tee Joint Box?

What is the important role of Tee Joint Box?

What are the product features of Tee Joint Box?

1. The Tee Joint Box adopts a cast aluminum alloy shell, and the surface is sprayed with plastic.

2. The side cover of the Tee Joint Box is opened for easy installation and maintenance.

3. Special Tee Joint Box can be made if required.

4. Tee Joint Boxcan use steel pipe or cable wiring.

5. Anti-twist special terminal, safe and reliable, easy to connect;

6. The thread type of the inlet port is usually pipe thread, and it can also be processed into metric thread or NPT thread according to requirements

What are the steps to use the Tee Joint Box?

First open the junction box of the electric heating cable, and at the same time unscrew the nut of the electrode terminal; then put the two core wires of the electric heating cable on the two electrode columns, tighten the nut of the electrode, and let the pressure plate press the core wire of the heating cable. , the Tee Joint Box must not be loosened; then place the waterproof gasket and cover on the box, and fix the nut; finally, the junction box should be sealed against moisture and water, and it is necessary to avoid the occurrence of parallel wires or wires. It is the case where the wire is exposed.

What is the important role of Tee Joint Box?

1. When the pipeline encounters a bifurcation, the intermediate Tee Joint Box can be used to make the electric heating cable branch out, which can be used for the heating of the pipeline with complex network.

2. The Tee Joint Box is used to fix the connection of the electric heating cable, and it is not easy to fall off, so as to avoid the situation that the electric heating cable does not generate heat.

3. When the electric heating cable fails, the Tee Joint Box facilitates the search and determination of the fault point, and facilitates the replacement of a certain section of the electric heating cable.

4. A Tee Joint Box must be installed at the end of the electric heating cable to prevent the cable core from being corroded by moisture and isolated from the live conductor. During installation, the sealed terminal and the junction box should be avoided from being immersed in liquid.

Note: Tee Joint Box can be used with silicone in wet environment.

If you are interested in the Tee Joint Box and want to know more information, please contact Guangzhou HERUI.
